WFI-Distillation plant
Item No.:2064
Manufacturer:DEWA
Type:DP 30 EVS
Year:2000
Location:Dettingen (89547)
Additional Information
Other Information:Distillation or pure steam system
This system can be used to produce either distillate or pure steam.
Production 30 litres/h
Feed water consumption 35 l/h
Cooling water consumption system at 95 °C distillate water
200 l/h
Electrical heating capacity 18 kW
Max. operating pressure 1.9 bar
min. Cooling water pressure 1.0 bar
min. Feed water pressure 1.0 bar
min. Pressure for control air 6.0 bar
Total evaporator capacity approx. 27 litres
Evaporator capacity at max. level approx. 11 litres
Equipment: Dimensions:
Height 2240 mm
Width 970 mm
Depth 700 mm
Unladen weight 300 kg
Documents available
